NITROWEAR® is a proprietary and patented combination process where increased corrosion resistance above and beyond the what DYNA-BLUE® provides is needed. The process incorporates a proprietary oil spray or dip after the part has been processed with DYNA-BLUE® for corrosion resistance of approx. 96-120 hours salt spray resistance per ASTM B-117, which is better than 409 Stainless Steel. NITROWEAR™ provides the same benefits as DYNA-BLUE® with additional corrosion resistance.
Benefits
- High wear resistance- surface hardness, typically greater than Rockwell “C” 75.
(Click here for microhardness graph)
- High corrosion resistance: 168+ Salt Spray hours when combined with our NITROWEAR Dip/Spray
(Click here for test results)
- High levels of Residual Compressive Stress to resist heat checking, fatigue and cracking.
- Lower co-efficient of friction, as low as .03.
(Click here for test results)
- Low dimensional variation: .0001"-.0002 growth per side.
- Anti-galling & anti-sticking properties.
- Maintains excellent micro finish.
- Not limited by component geometry or line of sight.
- 100% environmentally friendly.
- Better weldability than traditional nitriding or ion nitriding.
(Click here for testimonial)
- Capacity 42"x 134" and 75"x 120", up to 30,000 lbs.
- Hard surface hardness maintains ductility, durability testing has shown that DYNA-BLUE® can bend up to 90° without cracking.
- Overnight service is available
